| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
USA
TX: 144.000-147.9875 MHz
RX: 144.000-147.9875 MHz
|
| Tuning steps: | Channelized in 12.5 / 25 KHz steps |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
320
|
| Repeater shift / offset: | -600 KHz |
| Power supply: | 10-16 VDC |
| Current drain / power consumption: | RX: 300 mA
TX: Max 8 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 156*58*290 mm (6.14*2.28*11.42") |
| Weight: | 2.3 Kg (5.07 lb) |
| Other features: | 1750 Hz tone burst |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | 1 uV (25 dB SINAD) |
| Selectivity: | 7.5 KHz (-6 dB) |
| Image rejection: | Better than 60 dB |
| AF output power / speaker: | ? W at ?% distortion / ? ohms |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
100% duty cycle!
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-1980 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
