| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
66-88 / 108-174 / 406-512 MHz (Europe)
|
| Tuning steps: | ? KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
16 regular @ 15 channels per second
|
| Power supply: | Mains or 13.8 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 225*60*165 mm (8.86*2.36*6.5") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 450 KHz - Ceramic filter: Murata SFR-450D
|
| Sensitivity: | |
| Selectivity: | 20 KHz (-6 dB)
40 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | (By Uniden), 19xx-19xx (Discontinued) |
| Additional info: | |
| Related documents: |
FM-IF: MC3359
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
