| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
148-174 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
7 regular @ 10 channels per second
XTAL controlled
VFO on channel 8
Priority function
|
| Power supply: | Mains: 120 VAC
or 12 VDC |
| Current drain / power consumption: | ? mA @ 12 VDC |
| Antenna impedance / connector: | 50-75 ohm / ? |
| Dimensions (W*H*D): | 238*76*244 mm (9.38*3*9.62") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.7 uV (20 dB noise quieting) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1973-1973 (Discontinued) |
| Additional info: | New price 1973 in the US: $159.95 |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
