| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
USA
29-54 / 108-174 / 406-512 / 806-823 / 851-868 / 896-956 MHz
|
| Tuning steps: | VHF low/high: 5 KHz
Airband & UHF: 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
100 regular in 5 banks @ 14 channels per second
Priority function
|
| Power supply: | 12 VDC ±10% |
| Current drain / power consumption: | 230-500 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 160*41*188 mm (6.3*1.61*7.4") |
| Weight: | 1 Kg (2.2 lb) |
| Other features: | Weather channels. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.8 MHz
2nd IF: 450 KHz
|
| Sensitivity: |
30-50 MHz: 0.5 uV (12 dB S/N)
118-135 MHz: 1.6 uV (12 dB S/N)
140-170 MHz: 0.7 uV (12 dB S/N)
410-510 MHz: 0.7 uV (12 dB S/N)
810-950 MHz: 0.8 uV (12 dB S/N)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: |
18 KHz (-6 dB)
30 KHz (-50 dB)
|
| Image rejection: | 60 dB (At 155 MHz) |
| AF output power / speaker: | 1 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines (By Uniden. Designed in USA) 1992-199x (Discontinued) |
| Additional info: |
FCC ID: AAO20-148
New price 1993 in the US: $199.95
New price 1994 in the US: $229.99
New price 1995 in the US: $229.99 (From now on under the RadioShack brand)
New price 1996 in the US: $249.99
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | Popular Communications: November 1992, page 20 |
| Options / Accessories: |
|
