| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
USA
30-54 / 118-174 / 380-512 / 806-824 / 849-869 / 894-960 MHz
|
| Tuning steps: | VHF low/high: 5 KHz
Airband: 25 KHz
UHF: 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
200 regular in 10 banks @ 25 channels per second
10 monitor
1 priority
|
| Power supply: | Mains: 120 VAC (Fixed power cord)
or 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Max 13 W @ 120 VAC
Max 8 W @ 13.8 VDC |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 214*83*173 mm (8.42*3.27*6.81") |
| Weight: | 1.1 Kg (2.42 lb) |
| Other features: | 10 dB attenuator. HyperScan. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 257.5 MHz
2nd IF: 21.4 MHz
3rd IF: 455 KHz
|
| Sensitivity: |
AM (20 dB S/N, 60% modulation)
108-137 MHz: 2 uV
FM (20 dB S+N/N)
30-54 MHz: 1 uV
137-174 MHz: 1 uV
380-512 MHz: 1 uV
806-960 MHz: 2 uV
|
| Squelch sensitivity: | Less than 1 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 20 KHz (-6 dB)
40 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 1 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By GRE), 1994-199x (Discontinued) |
| Additional info: |
FCC ID: AAO020-461
New price 1995 in the US: $299.99
New price 1996 in the US: $329.99
New price 1997 in the US: $299.99
|
| Related documents: | User manual (11.8 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
