| GENERAL |
| Type: | Professional VHF transceiver |
| Frequency range: | 136-174 MHz |
| Tuning steps: | 2.5 / 3.125 KHz |
| Mode: | FM/NFM/IDAS (FDMA) |
| Memory channels: | 512 (128 zones) |
| Power supply: | 13.6 VDC nominal |
| Current drain/power consumption: | RX: 0.3-1.2 A
TX: Max 14 A |
| Antenna impedance/connector: | 50 ohms / SO-239 |
| Dimensions (W*H*D): | 160*45*150 mm |
| Weight: | 1.31 Kg (2.9 lb) |
| Other features: | Built-in standard inversion type scrambler.
Analog FM: 2-tone, 5-tone, CTCSS/PL, DTCS, DTMF autodial, Lone worker and more
Digital IDAS: PTT ID, Stunn/kill/revive, DV scrambler, Emergency, GPS and more |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: | Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz |
| Sensitivity: | FM/NFM: 0.25 uV (12 dB SINAD)
IDAS: 0.2 uV (5% BER) |
| Selectivity: | |
| Image rejection: | |
| AF output power/speaker: | 4 W at 5% distortion / 4 ohms |
| External speaker connector: | 3.5 mm mono / 4 ohms |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | Max 50 W |
| Modulation system: | |
| Max FM deviation: | FM: ±5 KHz
NFM/IDAS: ±2.5 KHz |
| Spurious emissions: | Less than -75 dB |
| Microphone connector/impedance: | 8-pin modular / 600 ohms |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2008-201x |
| Additional info: | |
| Related documents: | |
| Modifications: | |
| Options/Accessories: |
HM-148G
HM-152
HM-152T
OPC-607
OPC-608
OPC-609
RMK-3
SM-25
SP-5
SP-10
SP-22
UT-109R
UT-110R |
Heavy duty microphone
Standard hand microphone
DTMF microphone
Separation cable, 3 m (9.8 ft)
Separation cable, 8 m (26.2 ft)
Separation cable, 1.9 m (6.2 ft)
Separation kit
Desktop microphone
Large external speaker
Mid sized external speaker
Compact external speaker
Non-rolling type scrambler, 32 codes
Rolling-type scrambler, 1020 codes |
|
