| GENERAL |
| Type: | Professional land mobile transceiver |
| Frequency range: | 68-88 MHz (Any 1.2 MHz segment according to alignment) |
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
12 regular (Two XTALs per channel)
|
| Repeater shift / offset: | According to XTALs |
| Power supply: | 10.8-33 VDC |
| Current drain / power consumption: | RX: 160 mA
TX: 2 A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 181*52*170 mm (7.13*2.05*6.69), behind the front panel |
| Weight: | 1.2 Kg (2.65 lb) |
| Other features: | Various selcall options. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.25 uV (No reference) |
| Squelch sensitivity: | |
| Selectivity: | 75 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 3 W at 5% distortion / No internal speaker |
| External speaker connector: | 3 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 10 W |
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than 0.2 uW |
| Microphone impedance / connector: | 50-200 ohm / ?-pin |
| Microphone input level: | 1 mV (No reference) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Sweden, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
