| Type: | Amateur UHF linear amplifier |
| Frequency range / band(s): | 430-450 MHz (70 cm) |
| Output power: | FM: Max 50 W
SSB: Max 60 W |
| Drive power: | 1-10 W |
| Power supply: | 13.8 VDC (Fixed power cord) |
| Current drain / power consumption: | Max 9 A |
| Impedance / connectors: | 50 ohm / Radio: SO-239. Antenna: N-jack |
| Dimensions (W*H*D): | 100*50*200 mm (3.94*1.97*7.87") |
| Weight: | 1 Kg (2.2 lb) |
| Manufactured: | Japan, 1983-198x (Discontinued) |
| Other: |
Built-in 15 dB GaAs-FET preamp (3SK97).
New price 1984 in Sweden: SEK 1995:-.
New price, march 1985 in the UK: £179.00
|
| Related documents: |
RF final: One 2SC2905
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
