RM Italy KL-503HD "High Drive"
SPECIFICATIONS
| Type: | HF linear amplifier |
| Frequency range / band(s): | 25-30 MHz (10 / 11 m) |
| Output power: | Max 300 W (PEP) |
| Drive power: | 1-35 W |
| Power supply: | 13.6 VDC |
| Current drain / power consumption: | Max 30 A |
| Impedance / connectors: | 50 ohm / Two SO-239 |
| Dimensions (W*H*D): | 190*66*260 mm (7.48*2.6*10.24"), including cooling fins |
| Weight: | 2.11 Kg (4.65 lb) |
| Manufactured: | Italy, 2018-202x |
| Other: |
Built-in peamp
New price, december 2022 in Sweden: SEK 3995:-
|
| Related documents: | User manual (6.3 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
|
