| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
75-88 / 161-175 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
14 regular
2 out of 12 local
XTAL controlled
|
| Power supply: | 12 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Less than 670 mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 192*64*210 mm (7.56*2.52*8.27") |
| Weight: | 1.7 Kg (3.75 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
