| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
0.1-1300 MHz
|
| Tuning steps: | 5 / 6.25 / 10 / 12.5 / 25 / 30 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
100 regular
|
| Power supply: | 6-7.5 VDC (Five LR6 / AA batteries)
or 6-15 VDC external |
| Current drain / power consumption: | 35-200 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 47*121*31 mm (1.85*4.76*1.22") |
| Weight: | 290 g (10.23 oz) |
| Other features: | 100 mW TX between 430-440 MHz! |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 254.25 MHz
2nd IF: 10.7 MHz
3rd IF: 455 KHz
|
| Sensitivity: |
AM (10 dB S/N)
0.1-50 MHz: 1.6 uV
50-789 MHz: 0.8 uV
789-1300 MHz: 1.6 uV
FM (12 dB SINAD)
0.1-50 MHz: 0.8 uV
50-789 MHz: 0.4 uV
789-1300 MHz: 0.8 uV
WFM (12 dB SINAD)
0.1-50 MHz: 6.3 uV
50-789 MHz: 3.16 uV
789-1300 MHz: 8 uV
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 100 mW at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 199x-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
