| GENERAL |
| Type: | VHF receiver |
| Frequency range: |
150-175 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
24 regular
XTAL controlled
|
| Power supply: | Mains: 117 VAC
or 13.8 VDC
(6-pin Jones connector) |
| Current drain / power consumption: | ? mA @ 13.8 VDC |
| Antenna impedance / connector: | 50-75 ohm / RCA (Phono) |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | RCA (Phono) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1970-197x (Discontinued) |
| Additional info: |
New price 1970 in the US: $169.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
