| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
30-50 MHz (Any 10 MHz segment depending on alignment. 37-47 MHz from factory)
140-174 MHz (Any 12 MHz segment depending on alignment. 151-163 MHz from factory)
|
| Tuning steps: | Channelized |
| Frequency stability: | ?% |
| Mode: | FM |
| Channels/memory management: |
8 regular
One XTAL per channel
|
| Power supply: | 12 VDC
or mains: 120 VAC |
| Current drain/power consumption: | ? mA @ 12 VDC |
| Antenna impedance/connector: | 50-75 ohm / DIN41585 (Motorola)
or telescopic whip |
| Dimensions (W*H*D): | 152*64*203 mm (6*2.5*8") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Murata CFM455E
|
| Sensitivity: | 0.5 uV (20 dB quieting) |
| Squelch sensitivity: | 0.4 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 20 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / 3.2 ohm |
| External speaker connector: | RCA-Phono |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1973-197x (Discontinued) |
| Additional info: | |
| Related documents: |
Service manual (4.7 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
