| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
70-90 / 140-170 / 450-512 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
10 regular
XTAL controlled
|
| Power supply: | Mains: 220 VAC
or 13.8 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.4 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1977-1978 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
