| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
70-90 / 450-512 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
Scans up to 14 regular and 1+1 out of 12+12 "Local"
Sockets for 14 + 24 XTALs
|
| Power supply: | Mains: 220 VAC
or 12 VDC |
| Current drain / power consumption: | ? mA @ 12 VDC |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 192*62*203 mm (7.56*2.44*7.99") |
| Weight: | 1.54 Kg (3.4 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1976-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
