| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
25-520 / 760-1300 MHz
|
| Tuning steps: | 5 / 12.5 / 30 / 50 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
400 regular @ 26 channels per second
|
| Power supply: | Mains or 12 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 220*76*205 mm (8.66*2.99*8.07") |
| Weight: | 2.2 Kg (4.85 lb) |
| Other features: | Sound squelch. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
AM (20 dB S/N):
25-1000 MHz 2 uV
1000-1300 MHz 5 uV
FM (20 dB S/N):
25-1000 0.5 uV
1000-1300 MHz 3 uV
WFM (30 dB S/N):
25-1000 MHz 3 uV
1000-1300 MHz 10 uV
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By GRE), 1995-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
