| GENERAL |
| Type: | VHF / UHF receiver |
| Frequency range: | VHF Lo-Hi / UHF |
| Tuning steps: | Channelized |
| Frequency stability: | |
| Mode: | FM |
| Channels/memory management: |
8 regular
1 priority
XTAL controlled
|
| Power supply: | Mains: 117 VAC or 13.8 VDC (Male 4-pin jack) |
| Current drain/power consumption: | ? mA @ 13.8 VDC |
| Antenna impedance/connector: | 50 ohm / Three SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | 1/4-inch jack |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By Matsushita), 1975-1976 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
