| GENERAL |
| Type: | HF receiver |
| Frequency range: |
3.5-4 MHz
7-7.3 MHz
9.6-10 MHz
14-14.35 MHz
21-21.45 MHz
28-28.5 MHz
28.5-29.1 MHz
29.1-29.7 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | AM / SSB / CW |
| Channels / memory management: |
None
|
| Power supply: | Mains: 117 or 230 VAC |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | 50 ohm / Screw terminals |
| Dimensions (W*H*D): | 330*178*254 mm (13*7*10") |
| Weight: | 8.16 Kg (18 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 8.9-9.5 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 2 uV (10 dB S/N) |
| Selectivity: | SSB: 1.5 KHz (-6 dB) |
| Image rejection: | 50 dB |
| AF output power / speaker: | 1 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1969-1971 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
