| GENERAL |
| Type: | Marine HF transceiver |
| Frequency range: |
TX: 2.0-6.0 MHz
RX: 0.55-1.63 / 2.0-6.0 MHz
|
| Tuning steps: | Channelized (Marine band)
VFO (Medium wave) |
| Frequency stability: | Better than 0.005% (No temperature reference) |
| Mode: | AM |
| Channels / memory management: |
6 regular (XTAL controlled)
|
| Duplex shift / offset: | |
| Power supply: | 12 VDC |
| Current drain / power consumption: | RX: 1.3 A
TX: Max 14 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 270*159*343 mm (10.62*6.25*13.5") |
| Weight: | 6.8 Kg (15 lb) |
| Other features: | ANL. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: ?
|
| Sensitivity: | 10 uV for 100 mW audio output (Marine band) |
| Squelch sensitivity: | |
| Selectivity: | 6 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
75 W
|
| Modulation system: | Class B high level |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
