| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 155-163 MHz
RX: 155-163.275
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
All international, US and Canadian channels
L1, L2, L3, F1, F2 and F3 (Scandinavia)
Channel M and M2 (UK)
10 NOAA weather channels (USA)
16 private
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 10.8-15.5 VDC |
| Current drain / power consumption: | RX: 190-340 mA
TX: Max 5.5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 185*66*158 mm (7.4*2.6*6.2") |
| Weight: | 500 g (1.1 lb) |
| Other features: |
Channel 16 button. Dual/triwatch. Scanning (Some versions).
IP66 waterproof.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.5 uV (20 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 70 dB (Adjacent channel) |
| Image rejection: | 70 dB |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Less than 0.25 uW |
| Microphone impedance / connector: | ? ohm / 7-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2001-200x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (749 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
FM1000BK
FTM-5
LS60
THS-5
|
Flush mount kit
Hand microphone
Waterproof external speaker
Telephone handset
|
|
