| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 155.000-163.400 MHz
RX: 155.000-163.400 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±10 ppm @ -25 to +55°C (-13 to +131°F) |
| Mode: | FM |
| Channels / memory management: |
All international, US and Canadian channels
15 private
NOAA weather channels
Priority function
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 13.8 VDC ±20% |
| Current drain / power consumption: | RX: 0.5-1.5 A
TX: Max 6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 155*55*190 mm (6.1*2.16*7.48") |
| Weight: | 1.5 Kg (3.31 lb) |
| Other features: | Channel 16 button. Scanning. Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.35 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 4 W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -70 dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 199x-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
