| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 155-159 MHz
RX: 155-163.6 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±5 ppm @ -30 to +60°C (-22 to +140°F) |
| Mode: | FM |
| Channels / memory management: |
All US, Canadian and international channels
NOAA weather channels
10 expansion channels
Priority function
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: 600 mA
TX: Max 6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 244*91*65 mm (9.6*3.6*2.56") |
| Weight: | 1.4 Kg (3 lb) |
| Other features: |
DSC. Channel 16/9 button. Dual watch. Scrambler. Weather alert.
Scanning. MariTEL ready. Clock. GPS option (NMEA).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.3 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 80 dB (Adjacent channel) |
| Image rejection: | 80 dB |
| AF output power / speaker: | 4 W at 10% distortion / 4 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 2007-201x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
