| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 156.025-157.425 MHz
RX: 156.300-162.025 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±10 ppm @ -20 to +50°C (-4 to +122°F) |
| Mode: | FM |
| Channels / memory management: |
All international channels
4 private
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 12 / 24 VDC ±10% |
| Current drain / power consumption: | RX: 220 mA (Squelched)
TX: Max 4.5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 320*220*195 mm (12.6*8.66*7.68") |
| Weight: | 12 Kg (26.5 lb) |
| Other features: | Dual watch. Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne (Duplex channels)
1st IF: 15.3 MHz
2nd IF: 470 KHz
Triple conversion superheterodyne (Simplex channels)
1st IF: 10.7 MHz
2nd IF: 15.3 MHz
3rd IF: 470 KHz
|
| Sensitivity: | 0.4 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2.5 W at 7% distortion / 4 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 500 mW
|
| Modulation system: | Phase modulation |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Denmark, 1973-197x (Discontinued) |
| Additional info: | |
| Related documents: | User/service manual (19.8 MB, in danish) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
N163
|
AC power supply (110/127/220 VAC)
|
|
