| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 156.025-161.425 MHz
RX: 156.375-162.000 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±5 ppm @ -20 to +50°C (-4 to +122°F) |
| Mode: | FM |
| Channels / memory management: |
All international channels
Also UK channels M1 and M2
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 13.6 VDC |
| Current drain / power consumption: | RX: 200 mA (Standby)
TX: Max 6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 153*61*158 mm (6.02*2.4*6.22") |
| Weight: | 1.09 Kg (2.4 lb) |
| Other features: |
Channel 16 button. Class D DSC. Scanning. Dimmer.
CFR-46 waterproof. GPS option (NMEA).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.5 uV (20 dB SINAD) |
| Squelch sensitivity: | 0.25 uV (Threshold)
0.8 uV (Tight) |
| Selectivity: | 70 dB (Adjacent channel) |
| Image rejection: | 70 dB |
| AF output power / speaker: | 3 W at 10% distortion / 4 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Less than 0.25 uW |
| Microphone impedance / connector: | ? ohm / Fixed spiral cord |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By Pony Electric Corp.), 200x-200x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (465 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
