| GENERAL |
| Type: | Marine HF transceiver |
| Frequency range: |
Australia / Oceania
TX: 27.680-27.980 MHz
RX: 27.680-27.980 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | 0.001% @ 0 to 55°C (32 to 131°F) |
| Mode: | AM |
| Channels / memory management: |
12 regular (10 fitted from factory)
|
| Duplex shift / offset: | No |
| Power supply: | 10.8-15.2 VDC |
| Current drain / power consumption: | RX: 350-800 mA
TX: Max 1.6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 172*52*173 mm (6.77*2.05*6.81") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.4 uV (12 dB SINAD) |
| Squelch sensitivity: | 0.2 uV (Threshold)
10 uV (Tight) |
| Selectivity: | 12 KHz (-36 dB)
20 KHz (-60 dB) |
| Image rejection: | 90 dB |
| AF output power / speaker: | 3 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
4 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -65 dBc |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Australia, 200x-200x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (627 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
