| GENERAL |
| Type: | Marine HF transceiver |
| Frequency range: |
TX: 2-16 MHz
RX: 2-16 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | SSB |
| Channels / memory management: |
4 regular
XTAL controlled
|
| Duplex shift / offset: | |
| Power supply: | Mains: 110/230 VAC or 12 VDC (Depending on version) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 394*190*368 mm (15.5*7.5*14.5") |
| Weight: | 12.25 Kg (27 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
~50 W PEP (100 W PEP input)
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1966-196x (Discontinued) |
| Additional info: |
New price 1966 in the US: $1250 (AC version). $1300 (DC version).
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
