| GENERAL |
| Type: | VHF receiver |
| Frequency range: |
30-50 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ±?% |
| Mode: | FM |
| Channels / memory management: | - |
| Power supply: |
HA-50, mains: 117 VAC (Fixed power cord)
HA-50S, mains: 220 VAC (Fixed power cord)
|
| Current drain / power consumption: | Max 45 W |
| Antenna impedance / connector: | 50-75 ohm / Screw terminals |
| Dimensions (W*H*D): | 265*130*185 mm (10.43*5.12*7.28") |
| Weight: | 4.54 Kg (10 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 10.7 MHz
|
| Sensitivity: | 4 uV (20 dB quieting) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | 23 dB |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | 1/4" jack (Headphones) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1965-196x (Discontinued) |
| Reset procedure: | - |
| Additional info: | |
| Related documents: |
Flyer (1.3 MB, In swedish)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
