Lafayette HA-350

A picture of Lafayette HA-350

SPECIFICATIONS

GENERAL
Type:HF receiver
Frequency range: 10-80 m in seven bands
80 m:   3.5-4.0 MHz
40 m:   7.0-7.5 MHz
20 m:   14.0-14.5 MHz
15 m:   21.0-21.5 MHz
10 m:   28.0-28.5 MHz
10 m:   28.5-29.1 MHz
10 m:   29.1-29.7 MHz
Plus WWV on 15 MHz
Tuning steps:Analog / continuous
Frequency stability:? ppm
Mode:AM / SSB / CW
Channels / memory management: None
Power supply:Mains: 110-120 VAC
Current drain / power consumption:? W
Antenna impedance / connector:50-75 ohm / SO-239
Dimensions (W*H*D):381*190*254 mm (15*7.5*10")
Weight:11.34 Kg (25 lb)
Other features:100 KHz XTAL calibrator. ANL.




RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 3.5-4.1 MHz
2nd IF: 455 KHz
Sensitivity:1 uV (10 dB S/N)
Selectivity:2 KHz (-6 dB)
6 KHz (-60 dB)
Image rejection:40 dB
AF output power / speaker:1 W at ?% distortion / No internal speaker
External speaker connector:Screw terminals, 8 and 500 ohm




MISCELLANEOUS
Manufactured:Japan (By Trio), 1964-1968 (Discontinued)
Additional info: 12 tubes
New price 1965 in the US: $189.50
New price 1967 in the US: $129.95
New price 1968 in the US: $129.95
Related documents:User manual (1.8 MB)
Modifications and fixes:
Reviews:
Options / Accessories:
HA-94
HE-48
Matching speaker
External speaker
An inside picture of Lafayette HA-350
