| GENERAL |
| Type: | VHF receiver |
| Frequency range: |
155-157 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
6 regular
One XTAL per channel
|
| Power supply: | 12 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 152*53*200 mm (6*2*8") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Nippon Tokushu Togyo ADR-04-30B
|
| Sensitivity: | 0.7 uV (20 dB quieting) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1967-196x (Discontinued) |
| Additional info: | New price 1967 in the US: $99.95 (Less XTALs) |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
HB-502
HB-502B
|
Base station AC power supply (117 VAC)
Base station AC power supply
|
|
