| GENERAL |
| Type: | HF/VHF receiver |
| Frequency range: |
0.54-470 MHz in six bands
| AM: | 0.54-1.6 MHz |
| SW: | 4-12 MHz |
| PB Lo: | 30-50 MHz |
| FM: | 88-108 MHz |
| PB Hi: | 147-174 MHz |
| UHF: | 450-470 MHz |
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM (Depending on band) |
| Channels / memory management: |
None
|
| Power supply: | Mains: 117 VAC
or 6 VDC (Four LR14 / C batteries) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | ? ohm / ?
- / Two telescopic whips
- / Ferrite bar for the AM band |
| Dimensions (W*H*D): | 292*197*89 mm (11.5*7.75*3.5") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1971-1973 (Discontinued) |
| Additional info: |
New price 1972 in the US: $89.95
New price 1973 in the US: $94.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
