| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
Europe
76-108 / 108-500 MHz
USA
88-108 / 108-500 MHz
|
| Tuning steps: |
5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 / 125 / 200 KHz
|
| Frequency stability: | ±2.5 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | AM / AM-N / FM / FM-N / WFM |
| Channels / memory management: |
2000 regular in 100 groups (Banks) @ up to 150 channels per second
200 auto memory write
100 scan skip
25 scan edge pairs
Alpha tags (16 characters)
Group link scan
Non-volatile storage
|
| Power supply: | 3.6 VDC (Battery pack)
or 5 VDC external USB charging only |
| Current drain / power consumption: |
Typical @ single band, recording off, backlight off
Receiving: 380 mA
Standby: 150 mA
Power save: 80 mA
|
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 58*116*34 mm (2.3*4.6*1.3") |
| Weight: | 260 g (9.2 oz), with battery pack and antenna |
| Other features: |
Color screen. Bluetooth v5.2. Dual watch. Clock. CI-V. Digital recorder.
Micro-SD card slot. USB-C jack. Attenuator. VSC. Weather alert (USA only).
APO. Band scope. ANL. AF hi-cut filter. CTCSS/PL and DTCS with tone scan.
Duplex operation. Simple mode. Cloning. IPX7 compliant.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 58.050 MHz (A-band) - 57.150 MHz (B-band)
2nd IF: 450 KHz
|
| Sensitivity: |
AM (10 dB S/N)
108-142 MHz: 1.0 uV
222-250 MHz: 1.0 uV
250-300 MHz: 1.8 uV
300-400 MHz: 1.4 uV
FM (12 dB SINAD)
108-250 MHz: 0.4 uV
250-300 MHz: 0.71 uV
300-500 MHz: 0.56 uV
WFM (12 dB SINAD)
76-108 MHz: 1.0 uV
|
| Selectivity: |
AM/FM
50 dB or more (No reference)
WFM
35 dB or more (No reference)
|
| Image rejection: | |
| AF output power / speaker: | 400 mW at 10% distortion / 8 ohm |
| External speaker connector: | 3.5 mm (1/8") |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 2024-202x |
| Additional info: |
New price, july 2024 in Sweden: SEK 6495:-.
|
| Related documents: |
Basic manual (5.1 MB)
Advanced manual (6.3 MB)
C-IV reference (791 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BC-223
BC-258A
BC-258E
BC-258V
BP-287
BP-293
CS-R15
FA-S270C
LC-203
MB-127
SP-40
|
Rapid charger
AC adapter
AC adapter
AC adapter
Li-Ion battery pack. 3.6 V, 3280 mAh (Typical)
Battery case (Three LR6 / AA alkaline batteries)
Programming software
VHF/UHF antenna
Carrying case
Belt clip
Earphone
|
|
