| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
Japanese domestic market
TX: 51-54 MHz
RX: 51-54 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
5 regular
|
| Repeater shift / offset: | Duplex function |
| Power supply: | 3.6-4.5 VDC (Three R6 / AA alkaline or NiCd batteries) |
| Current drain / power consumption: | RX: 35-150 mA
TX: Max 150 mA (Simplex) - Max 300 mA (Duplex) |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 58*75*30 mm (2.3*3*1.2") |
| Weight: | 160 g (5.6 oz), with batteries and antenna |
| Other features: | VOX. Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: | Simplex: 0.22 uV (12 dB SINAD)
Duplex: 1.8 uV (12 dB SINAD) |
| Squelch sensitivity: |
Simplex: Typical 0.22 uV (Threshold)
Duplex: Typical 1.8 uV (Threshold)
|
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 150 mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Simplex: 150 mW
Duplex: 50 mW
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1989-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BC-74
CP-12
FA-50
HM-46
HS-58
HS-59
LC-69
MB-24
MB-25
OPC-254
|
Wall charger. 100 VAC
Cigarette lighter DC cable
Flexible antenna
Speaker-microphone (For simplex only)
Headset
Microphone-earphone set
Carrying case
Mounting bracket (Hanger type)
Mounting bracket (Wall type)
DC power cable
|
|
