| GENERAL |
| Type: | Amateur UHF transceiver |
| Frequency range: |
Japanese domestic market
TX: 1260-1300 MHz
RX: 1260-1300 MHz
|
| Tuning steps: | 10 / 20 / 30 / 40 / 50 KHz |
| Frequency stability: | ±5 ppm @ 0° to 50°C (32° to 122°F) |
| Mode: | FM |
| Channels / memory management: |
10 regular
RAM storage with lithium battery backup
|
| Repeater shift / offset: | ±20 MHz (Default, programmable) |
| Power supply: | ~9 VDC (Depending on battery pack)
or 13.8 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | RX: 65-250 mA
TX: 400-900 mA |
| Antenna impedance / connector: | 50 ohm / TNC |
| Dimensions (W*H*D): | 65*181*36 mm (2.56*7.12*1.42") |
| Weight: | 645 g (1.42 lb) |
| Other features: | RIT/VXO. CTCSS/PL encoder. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 59.55 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.32 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 15 KHz (-6 dB)
30 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 500 mW at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / TS "Subminijack" (2.5 mm) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications: | |
| Reviews: | |
| Options / Accessories: |
|
