| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
10 NOAA weather channels
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: Less than 380 mA
TX: Less than 1.2 A |
| Antenna impedance / connector: | 50 ohm / SMA female |
| Dimensions (W*H*D): | 60*115*36 mm (2.4*4.5*1.4") |
| Weight: | 300 g (10.6 oz) |
| Other features: |
CTCSS/PL and DCS. USB-C charging. LED flashlight.
Noise reduction (NRC). Digital voice recorder (Replay).
Weather alert. Dimmer. VOX. Roger beep. IP67 waterproof.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 1 W at ?% distortion / ? ohm |
| External speaker connector: | TRS "Subminijack" (2.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / TRS "Minijack" (3.5 mm) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Additional info: |
FCC ID: 2AN62-X1PRO
New price, july 2026 in the US: $55.99
|
| Related documents: |
User manual (6.2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
BL-X1PRO
|
Li-Ion battery pack. 7.4 V, 3000 mAh / 22.2 Wh
|
|
