| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 400-470 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5 / 6.25 / 12.5 / 25 / 50 / 100 KHz |
| Frequency stability: | ±300 Hz @ -30 to +60°C (-22 to +140°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS
8 repeater
50 custom
10 NOAA weather
Alpha tags
Scanning and dual watch
Priority function
|
| Repeater capable: | Yes |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: 360 mA
TX: Less than 5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | Main unit: 187*53*175 mm (7.4*2.1*6.9")
Control mike: ? mm (?") |
| Weight: | Main unit: ? Kg (? lb)
Control mike: ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. RX/TX noise canceling (NRC). VOX. Roger beep.
NOAA weather alert. Call tone. Voice recording and playback.
7 color selectable backlite.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1 W at 5% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM (Wide): ±5 KHz
NFM (Narrow): ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 8-pin (Modular) |
| Microphone input level: | 5-10 mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Reset procedure: |
Enter the "Reset" menu and select "Yes" to restore the radio to its factory
settings.
|
| Additional info: |
New price, september 2026 in the US: $129.99 (With magmount antenna)
|
| Related documents: |
User manual (27 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
