| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.775 / 462.550-467.725 MHz
|
| Tuning steps: | TX: Channelized
RX: Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
28 GMRS with pre-programmed "privacy codes"
10 NOAA weather channels
Scanning
|
| Repeater capable: | |
| Power supply: | 13.8 VDC (Male 2-pin jack, on pigtail) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | Main unit: ? mm (?")
Microphone: ? mm (?") |
| Weight: | Main unit: K? g (? lb)
Microphone: ? g (? oz) |
| Other features: |
CTCSS/PL with split tones. PA. Bluetooth. Noise cancelling (ANC).
IP67 water and dustproof. Dual watch. Intercom function. Wireless
Bluetooth microphone with USB-C charging. A wired microphone may
also be used. Scan list editing. Dual watch. Roger beep. Call tone. VOX.
USB-C on the main unit for device charging.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm, on pigtail), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM "Wide": ±5 KHz
NFM "Narrow": ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 8-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-20xx (Discontinued) |
| Reset procedure: | |
| Additional info: |
FCC ID: MMAMXT295
New price, september 2026 in the US: $299.99 (Including a simpel magmount antenna)
|
| Related documents: |
User manual (1.5 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
