| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 403-520 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | Less than ±1.2 KHz @ -20 to +60°C (-4 to +140°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
15 GMRS simplex
8 GMRS repeater
400 RX only
1 priority
Scanning @ 50 channels per second
|
| Repeater capable: | Yes |
| Power supply: | 10-16 VDC (Male 2-pin jack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / FME |
| Dimensions (W*H*D): | 100*22*86 mm (3.92*0.87*3.39") |
| Weight: | 137 g (4.83 oz) |
| Other features: |
CTCSS/PL and DCS. Bluetooth for smartphone connectivity.
Voice playback. Active mute. Crewtalk. Speaker-microphone
with OLED display. Roger beep. Selcall function with unique ID.
Super compact design.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.18 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / No internal speaker in the main body |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
5 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dBc |
| Microphone impedance / connector: | ? ohm / 8-pin (RJ45 modular jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Australia, 2025-202x |
| Additional info: |
MSRP, november 2025 in the US: $375.00
|
| Related documents: |
User manual (5.5 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
