| GENERAL |
| Type: | HF/VHF receiver |
| Frequency range: |
0.15-30 / 87.5-108 / 118-137 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / AM-Sync / SSB / WFM Stereo |
| Channels / memory management: |
700 regular
|
| Power supply: | 4.8-6 VDC (Four LR6 / AA batteries) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | - / Internal telescopic whip and ferrite bar |
| Dimensions (W*H*D): | 168*105*28 mm (6.61*4.13*1.1") |
| Weight: | 345 g (12.17 oz) |
| Other features: | RDS. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | Clock. Sleep timer. Alarm. Line in (Aux). Headphone jack. |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2009-201x |
| Additional info: | |
| Related documents: | User manual (466 KB, multi language) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
