| GENERAL |
| Type: | DAB / FM receiver |
| Frequency range: |
87.5-108 MHz and Band III
|
| Tuning steps: | 50 KHz |
| Frequency stability: | ? ppm |
| Mode: | DAB / DAB+ / WFM with RDS |
| Channels / memory management: |
5 DAB presets
5 WFM presets
|
| Display: | Color LCD |
| Power supply: | 12 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Less than 1 A |
| Antenna impedance / connector: | - / Fixed telescopic whip |
| Dimensions (W*H*D): | 206*127*117 mm (8.11*5*4.6") |
| Weight: | ? Kg (? lb) |
| Other features: |
Bluetooth. AUX input. Alarm clock/timer. Dimmer.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / ? ohm |
| External speaker connector: | TRS "Minijack" (3.5 mm), for headphones |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 202x-202x |
| Additional info: | |
| Related documents: |
User manual (4.2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
