| GENERAL |
| Type: | DAB / FM receiver |
| Frequency range: |
87.5-108 MHz and Band III
|
| Tuning steps: | 50 KHz |
| Frequency stability: | ? ppm |
| Mode: | DAB / DAB+ / WFM with RDS |
| Channels / memory management: |
40 DAB
40 WFM
|
| Display: | 1.8" color LCD |
| Power supply: | 6 VDC (Four LR6 / AA batteries
or 5 VDC external (USB) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | - / Fixed telescopic whip |
| Dimensions (W*H*D): | 165*101*53 mm (6.5*3.98*2.09") |
| Weight: | 290 g (10.23 oz) |
| Other features: |
ASA alert. USB-C. Alarm clock/timer. Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | TRS "Minijack" (3.5 mm), for headphones |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2026-20xx |
| Additional info: | |
| Related documents: |
User manual (338 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
