| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26-31 MHz |
| Channels / tuning steps: | 6 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±0.001% (No temperature reference) |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight LR6 / AA batteries or NiCd pack) |
| Current drain / power consumption: | RX: 14 mA (Squelched)
TX: Max 950 mA |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 85*245*60 mm (3.35*9.64*2.36") |
| Weight: | 1.05 Kg (2.31 lb) |
| Other features: | Selcall option. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.5 uV (10 dB S+N/N) |
| Squelch sensitivity: | |
| Selectivity: | 6 KHz (-6 dB)
20 KHz (-70 dB) |
| Image rejection: | |
| AF output power / speaker: | 1 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~2 W (3.5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 197x-1977 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1975 in Sweden: SEK 970:-
New price 1976 in Sweden: SEK 1030:-
New price 1977 in Sweden: SEK 1055:-
|
| Related documents: | |
| Known markets and approvals: |
Sweden
Televerket
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
