| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
TX/RX: 26-31 MHz
RX only: 26.965-27.255 MHz
|
| Channels / tuning steps: | TX/RX: 5 regular
RX only: VFO |
| Mode: | AM |
| Frequency control: | TX/RX: Two XTAL's per channel
RX only: Analog / continuous |
| Frequency stability: | |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC |
| Current drain / power consumption: | RX: ? mA
TX: Max 500 mA |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 255*95*140 mm (10.04*3.74*5.51") |
| Weight: | 2.25 Kg (4.96 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 5.5 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.8 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2.5 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3 W (5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 196x-197x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (2.4 MB)
|
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
