| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 1 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | 0.005% (No temperature reference) |
| Clarifier or Delta tune: | No |
| Power supply: | 9 VDC (One 6LR61 / 1604 / E battery) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | - / Fixed telescopic whip |
| Dimensions (W*H*D): | 61*142*39 mm (2.4*5.59*1.54") |
| Weight: | 350 g (12.34 oz) |
| Other features: | Battery meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 2.5 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | 6 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | 120 mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~60 mW (100 mW input) |
| Modulation system: | |
| Max AM modulation (Factory set): | 95% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 8 ohm / Internal only |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 196x-196x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (1.1 MB, In swedish)
|
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
West Germany
FTZ?
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
