| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
26.965-27.405 MHz
Can be used up to about 32 MHz or so (Depending on XTALs and alignment)
|
| Channels / tuning steps: | 6 |
| Mode: | FM |
| Frequency control: | One XTAL per channel |
| Frequency stability: | ±?% |
| Power supply: | 10.8-13.5 VDC (Nine R6 / AA alkaline or NiCd batteries)
or 12 VDC external (Male barrel jack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | Fixed telescopic whip
50 ohm / RCA-Phono |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? lb), with batteries |
| Other features: | NiCd charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ? W |
| Modulation system: | |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 6-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1990-199x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
FM TX chip: MC2833
|
| Known markets and approvals: |
Sweden
Televerket: RL 2134/90
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
