| GENERAL |
| Type: | Citizen band / "Freeband" / Export transceiver |
| Frequency range: |
Export mode
24.265-29.655 MHz
|
| Channels / tuning steps: | 480 (Hi 6 bands + Low 6 bands = 12 * 40) |
| Mode: | AM / SSB |
| Frequency control: | PLL |
| Frequency stability: | 0.003% @ -30 to +50°C (-22 to +122°F) |
| Clarifier or Delta tune: | Coarse (RX/TX): ±5 KHz
Fine (RX): ±1.5 KHz |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: ? A
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | PA. ANL/NB. Talkback. SWR meter. Echo chamber. Dimmer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB SINAD)
SSB: 0.25 uV (12 dB SINAD)
|
| Selectivity: | -60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | 3.5 mm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Max Pwr |
|---|
| AM: | 25 W (Carrier / dead key) / >100 W (PEP) |
| SSB (PEP): | >100 W |
|
| Modulation system: | |
| FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Metal locking ring connector) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Malaysia, 2023-202x |
| Main PCB: |
EPT990015Z by Ranger
SMD and through-hole components
|
| Sub PCBs: | |
| Additional info: |
New price, september 2023 in the US: $418.95
|
| Related documents: | |
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
