| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
CB: 26.965-27.405 MHz
WX: 161.650-163.275 MHz (RX only)
|
| Channels / tuning steps: | CB: 40
WX: 10 |
| Mode: | CB: AM
WX: FM |
| Frequency control: | PLL |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 13.8 VDC (Fixed power cord) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 149*44*203 mm (5.88*1.75*8") |
| Weight: | ? Kg (? lb) |
| Other features: | PA. ANL. Channel 9 button. RF gain. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 500 ohm / 5-pin (DIN 180°) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Thailand, 1994-1997 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1995 in the US: $99.99
New price 1996 in the US: $99.99
New price 1997 in the US: $99.99
|
| Related documents: | |
| Known markets and approvals: |
USA
FCC ID: AAO21-1557
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
