| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.405 MHz |
| Channels / tuning steps: | 40 |
| Mode: | AM |
| Frequency control: | PLL: uPD858 (Early)
PLL: uPD2816 (Later) |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | ±? KHz |
| Power supply: | Mains: 110, 220 or 240 VAC (Depending on market), fixed power cord
or 13.8 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: |
PA. ANL/NB. Alarm clock. SWR-meter.
Channel 9 switch. Delta tune.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | 3.5 mm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (Early) and Taiwan (Later), 1977-19xx (Discontinued) |
| Main PCB: |
Early: PC-198AA by Uniden
Later: PC-407AC by Uniden
|
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Approval / Market: |
Early
FCC Data: Dwight D / USA
Later
FCC Data: 1003002 / USA
Also exported and modified on other markets with unknown approvals
|
| Sams Photofact #: |
Early: CB-121 (May 1977)
Later: CB-229 (November 1978)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
