| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
26.965-27.255 MHz
Or any 300 KHz segment between 26-31 MHz depending to alignment)
|
| Channels / tuning steps: | 6 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 13.8 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: 180 mA
TX: Max 1.5 A |
| Antenna impedance / connector: | 52 ohm / SO-239 |
| Dimensions (W*H*D): | 121*38*162 mm (4.75*1.5*6.38") |
| Weight: | 1.09 Kg (2.4 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
455 KHz
|
| Sensitivity: | 1 uV (10 dB S/N) |
| Squelch sensitivity: | 1 uV (Threshold) |
| Selectivity: | 6 KHz (-6 dB)
20 KHz (-40 dB) |
| Image rejection: | |
| AF output power / speaker: | 700 mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3 W (5 W input) |
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / 6-pin DIN |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (2.2 MB)
Flyer (689 KB, In swedish)
|
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
Canada
D.O.C. No. 238401037
USA
FCC: Part 95 compliant
|
| Sams Photofact #: | CB-40 (June 1972) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
