| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM / SSB |
| Frequency control: | XTAL-matrix |
| Frequency stability: | ±0.003% (No temperature reference) |
| Clarifier or Delta tune: | AM ±1.5 KHz
SSB: ±600 Hz |
| Power supply: | Mains: 115 VAC
or 13.8 VDC |
| Current drain / power consumption: | RX: ? mA @ 13.8 VDC
TX: Max ? A @ 13.8 VDC |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 381*140*254 mm (15*5.5*10") |
| Weight: | 7.71 Kg (17 lb) |
| Other features: | Alarm clock. SWR-meter. ANL. PA. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 11.275 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB S+N/N)
SSB: 0.25 uV (10 dB S+N/N)
|
| Squelch sensitivity: |
AM
1 uV (Threshold)
1000 uV (Tight)
SSB
0.5 uV (Threshold)
200 uV (Tight)
|
| Selectivity: |
AM: 7 KHz (-6 dB)
SSB: 2.4 KHz (-6 dB)
|
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | AM: 4 W
SSB: 12 W (PEP) |
| Modulation system: | AM: High level, class B
SSB: Balanced with crystal lattice filter |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | 2 Kohm / 4-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1974-1974 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Market(s) / Approval(s): |
USA
FCC type accepted, class D, vol.6, part 95
|
| Sams Photofact #: | CB-62 (February 1975) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
