| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 2 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight R14 / C batteries)
or 12 VDC external |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: |
Fixed telescopic whip
or 50 ohm / ?
|
| Dimensions (W*H*D): | 230*130*55 mm (9.06*5.12*2.16") |
| Weight: | 1.8 Kg (3.97 lb) |
| Other features: | Battery and modulation meter. ANL. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 1 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 1 W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~600 mW (1 W input) |
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / One TS "Minijack" (3.5 mm) + one TRS "Subminijack" (2.5 mm) |
| Microphone input level: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1964-196x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1964 in Sweden: SEK 685:-
|
| Related documents: |
Flyer (1.1 MB, In swedish)
|
| Known markets and approvals: |
Sweden
Televerket
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
